A Bag Filter is a filtration device that uses a fabric bag to separate solid particles from a gas or liquid stream. In gas filtration (such as dust collectors), dusty air passes through fabric filter bags that trap particles, allowing clean air to exit. In liquid filtration, the liquid flows through a filter bag that captures suspended solids, letting clear liquid pass through.
APPLICATIONS
Water Treatment
Food & Beverages
Chemical Plants
Cement Industry
Power Plants
Wood Working
Petrochemical Industries
Pharma Industries
MAJOR COMPONENTS
Filter Bag – Made of woven or nonwoven fabric (e.g., polyester, polypropylene, PTFE).
Support – Metal frame inside the bag to prevent collapse.
Bag Housing– Steel casing to hold the bags and direct flow.
Inlet & Outlet Ducts – For dirty and clean gas/liquid.
Tube Sheet – Plate that holds bags in place.
Dust Collection Hopper - for dry dust applications.
